Used howo boom truck adopts a new LED headlight configuration, its lines are further simplified, combined with the application of LED light source, the reliability and lighting effect have been improved. Used boom truck cranes for sale can also be equipped with optional LED headlights with adaptive high and low beams, further enhancing driving convenience and safety.
Used howo boom truck is equipped with a sleeper cab, providing the driver with abundant living and storage space, and comfortable rest.
Used boom truck cranes for sale are equipped with original light racks, and the air horn, searchlight and rotating warning light and other accessories are placed forward, taking into account the practicality of the "slope" area on the top of the cab.
Used howo boom truck adopts a 6x4 drive form, in which the third and fourth bridges are drive bridges, providing excellent load-bearing capacity and traction, and achieving a balance in structural complexity.
Used 10 Ton Howo Boom Truck Crane for Sale in Ghana
Used 10 Ton Howo Boom Truck Crane for Sale in Ghana
Used 10 Ton Howo Boom Truck Crane for Sale in Ghana
Cabin: Cabin with two seats and one bed, with Air Conditioner
Engine Model: WD615.47
Horse Power (Hp/rpm): 371hp, Euro II Emission Standard
Type: 6-cylinder in-line with water cooling, turbo charger and intercooling, 4-stroke common rail diesel engine
Transmission: HW19710, 10 speeds forward and 2 speeds reverse.
Front Axle: HF9
Driving Axle: HC16
Suspension:
Front suspension: hydraulic telescopic double-action shock absorbers and stabilizer;
Rear suspension: leaf semi-elliptic springs, bogie spring and stabilizer
Steering System: ZF8118, Hydraulic steering with power assistance
Service brake: Dual circuit compressed air brake;
Parking brake: Spring energy, compressed air operating; Auxiliary brake: Engine exhaust brake
Tire: 12R22.5 Tires
Fuel Tank Capacity (L): 400L Diesel Tank
Overall Dimension(L*W*H)(mm): 10200×2500×3700
Body Dimension(L*W*H)(mm): 8500×2300×600
Max Lifting Capacity: 5000 kg
Recommend Power Needed At Recommend Oil Flow: 18 kw
Max Oil Flow of Hydraulic System: 32 L/min
Rated Pressure Of Hydraulic System: 18 Mpa
Rotation Angle: (360°)All Rotation
Crane Weight: 2170 Kgs
Installation Space: 900 mm
Wheelbase(mm): 5825+1350
Max. Speed (km/h): 90
A huge truck crane is mounted at the rear of the cab of the used howo boom truck. It is equipped with a telescopic arm and has a lifting torque of 20 tons.
The control panel of the used boom truck cranes for sale is located on the left side of the vehicle body and is equipped with a control handle. The truck crane is controlled by a radio remote control. The operator can stay away from danger and get a better and wider field of vision, which makes the work safer.
The rear outriggers are installed at the rear of the used howo boom truck, and the pads are stored next to them, supplemented by lateral LED work lights to enhance safety. The used boom truck cranes for sale itself comes with two outriggers, and two outriggers are installed in front of the bumper. There are a total of six outriggers in the whole vehicle to ensure stable parking and reduce the possibility of overturning during work.
The rear of the used howo boom truck is a large-sized cargo box with low sides and no top cover. It can transport various irregular goods well, and the interior is flat, which is convenient for fixing goods. In addition to using used boom truck cranes for sale for loading and unloading, you can also directly open the side panels and use forklifts and other equipment for loading and unloading.
Used howo boom truck has powerful power, bright configuration, and pleasing body details.
The cargo box carried by used boom truck cranes for sale mainly contains accessories, spare parts and consumables used in the transportation of large items. Used howo boom truck is designed with a towing hook at the rear and equipped with various electrical interfaces, which can additionally tow additional trailers to achieve stronger transportation capacity.
